Setting Up Our Playground

I've designed this demo to run in a DevContainer—think of it as a pre-configured development environment that works seamlessly with VSCode or Cursor. No more "it works on my machine" problems.

Everything is configured through environment variables with the .env file. I'm using uv for Python package management (because life's too short for slow dependency resolution).

I'm storing metadata in PostgreSQL via Supabase, a fully managed service that gives me the reliability of PostgreSQL without the operational overhead. Meanwhile, my actual data lives as Parquet files locally for the sake of this experimentation.

Getting started is straightforward. First, grab your Supabase credentials (it's free and takes about 2 minutes to set up), then configure your environment:

Copy code
cp .env.example .env

Your .env file will look something like this:

Copy code
# Required Supabase PostgreSQL credentials
SUPABASE_HOST=your-supabase-host.pooler.supabase.com
SUPABASE_PORT=6543
SUPABASE_DATABASE=postgres
SUPABASE_USER=postgres.your_project_ref
SUPABASE_PASSWORD=your_actual_password

# Optional (uses defaults if not specified)
DATA_PATH=/workspaces/tutorial-spark-ducklake/datalake

Creating Our First DuckLake

There's a quirky limitation worth mentioning: at this point in time, Spark can't specify the DATA_PATH through JDBC connections when creating new DuckLakes. So, before Spark can work its magic, we'll use DuckDB to bootstrap my DuckLake using DuckDB itself. Think of this as laying the foundation of my lakehouse—it's a one time operation and I'm populating it with some sample data.

The bootstrap script uses the TPC-H extension to generate sample data—around 60,000 lineitem records that simulate real-world transactional data.

Here's the bootstrap script in action:

Copy code
#!/usr/bin/env python3
import duckdb
import os
from loguru import logger
from dotenv import load_dotenv

def create_ducklake_with_data(data_path=None):
    """Create a Ducklake with PostgreSQL metadata and local data storage."""

    # Load environment variables
    load_dotenv()

    # Use default data path if not specified
    if data_path is None:
        data_path = os.getenv('DATA_PATH', '/workspaces/tutorial-spark-ducklake/datalake')

    # Ensure data path exists
    os.makedirs(data_path, exist_ok=True)

    conn = duckdb.connect()

    # Install required extensions
    logger.info("📦 Installing extensions...")
    conn.execute("INSTALL ducklake;")
    conn.execute("INSTALL postgres;")
    conn.execute("INSTALL tpch;")

    # Create PostgreSQL secret using environment variables
    host = os.getenv('SUPABASE_HOST')
    port = os.getenv('SUPABASE_PORT', '6543')
    user = os.getenv('SUPABASE_USER')
    password = os.getenv('SUPABASE_PASSWORD')

    conn.execute(f"""
        CREATE SECRET (
            TYPE postgres,
            HOST '{host}',
            PORT {port},
            DATABASE postgres,
            USER '{user}',
            PASSWORD '{password}'
        );
    """)

    # Create Ducklake with PostgreSQL metadata + local data
    conn.execute(f"""
        ATTACH 'ducklake:postgres:dbname=postgres' AS ducklake_catalog (
            DATA_PATH '{data_path}'
        );
    """)

    # Generate TPC-H data in memory, then copy to Ducklake
    conn.execute("USE memory;")
    conn.execute("CALL dbgen(sf = 0.1);")  # ~60K lineitem records

    conn.execute("USE ducklake_catalog;")
    conn.execute("CREATE TABLE lineitem AS SELECT * FROM memory.lineitem;")

    conn.close()

Running this is as simple as:

Copy code
uv run python bootstrap_ducklake.py

It's creating a DuckLake catalog backed by PostgreSQL for metadata, generating TPC-H benchmark data in memory, and then copying it into my new lakehouse. The end result? A fully functional DuckLake with real data, ready for Spark to consume.

You know should have some data in your local datalake folder

Copy code
datalake
└── main
    └── lineitem
        └── ducklake-019885e5-8bef-70b7-9576-ef653bc472ce.parquet

You can also go to the Supabase UI and inspect the metadata tables.

Two Ways to Read from DuckLake with Spark

Now comes the fun part—getting Spark to talk to my DuckLake. There are two distinct approaches, each with its own personality and use cases.

Copy code
uv run python spark_dataframe_read.py

Copy code
# Step 1: Get partitioning information for optimal performance
partitioning_info = (
    jdbc_setup().option('query', f'''
        SELECT
            min(file_index::BIGINT)::STRING min_index,
            (max(file_index::BIGINT)+1)::STRING max_index,
            count(DISTINCT file_index::BIGINT)::STRING num_files
        FROM "{table_name}"''').load().collect()[0])

Copy code
# Step 2: Read with custom partitioning
table_df = (jdbc_setup()
    .option('dbtable', f'(SELECT *, file_index::BIGINT __ducklake_file_index FROM "{table_name}") "{table_name}"')
    .option('partitionColumn', '__ducklake_file_index')
    .option('lowerBound', partitioning_info['min_index'])
    .option('upperBound', partitioning_info['max_index'])
    .option('numPartitions', partitioning_info['num_files'])
    .load())

Copy code
uv run python spark_sql_read.py

Copy code
# Step 1: Create database and discover tables
spark.sql("CREATE DATABASE IF NOT EXISTS ducklake_db")
spark.sql("USE ducklake_db")

# Step 2: Discover available tables via information_schema
spark.sql(f"""
    CREATE OR REPLACE TEMPORARY VIEW ducklake_tables
    USING jdbc
    OPTIONS (
        url "{duckdb_url}",
        driver "org.duckdb.DuckDBDriver",
        dbtable "information_schema.tables"
    )
""")

Copy code
# Step 3: Create persistent Spark table
spark.sql(f"""
    CREATE TABLE lineitem
    USING jdbc
    OPTIONS (
        url "{duckdb_url}",
        driver "org.duckdb.DuckDBDriver",
        dbtable "lineitem"
    )
""")

# Step 4: Query using standard SQL
result = spark.sql("""
    SELECT l_returnflag, l_linestatus, COUNT(*) as count
    FROM lineitem
    GROUP BY l_returnflag, l_linestatus
""")
result.show()

Writing Data: From CSV to DuckLake via Spark

Now let's flip the script and explore writing data to my DuckLake using Spark. I'll load sales data from CSV files stored in ./data, process it with Spark, write it to DuckLake, and then verify everything worked correctly.

Copy code
uv run python spark_dataframe_write.py

The write script demonstrates something I find quite practical—it automatically generates sample data if none exists. This means you can run the demo immediately without worrying about data setup:

Copy code
def ensure_sample_data():
    """Ensure sample data exists by generating it if needed."""
    csv_path = "./data/sales_data.csv"
    if not os.path.exists(csv_path):
        # Auto-generate sample data if missing
        subprocess.run(["python", "generate_sample_data.py"], check=True)
    return csv_path

The data loading itself is straightforward, but I've included automatic schema inference to make the process as smooth as possible:

Copy code
def load_sales_data_from_csv(csv_path="./data/sales_data.csv"):
    """Load sales data from CSV file."""
    df = (spark.read
          .option("header", "true")
          .option("inferSchema", "true")  # Let Spark infer schema automatically
          .csv(csv_path))

    logger.success(f"✅ Loaded {df.count():,} sales records from CSV")
    return df

The script also demonstrates append operations, which is crucial for real-world scenarios where you're continuously adding new data:

Copy code
def demonstrate_append_mode():
    """Demonstrate appending additional data."""
    additional_csv = "./data/additional_sales_data.csv"
    additional_data = load_sales_data_from_csv(additional_csv)

    # Write in append mode
    if write_to_ducklake(additional_data, 'spark_sales_data', mode='append'):
        logger.success("✅ Append operation successful")
        read_and_verify('spark_sales_data')

The beauty of this approach is how it leverages Spark's built-in write modes (overwrite, append, ignore, error) while adding DuckLake's transactional guarantees on top.

After running the script, you will see in your ./datalake folder new data :

Copy code
datalake
└── main
    ├── lineitem
    │   └── ducklake-019885e5-8bef-70b7-9576-ef653bc472ce.parquet
    └── spark_sales_data
        ├── ducklake-019885e9-a968-722e-bd2f-587d1c0785ac.parquet

Exploring Your Lakehouse with DuckDB CLI

One of the most satisfying moments in this entire workflow is connecting to my DuckLake with the DuckDB CLI (or any DuckDB client) and seeing all my Spark-written data sitting there, complete with full lakehouse capabilities.

You can dive into the lakehouse using DuckDB's native tools:

Copy code
-- Connect to your Ducklake
INSTALL ducklake;
INSTALL postgres;

CREATE SECRET (
    TYPE postgres,
    HOST 'your-host',
    PORT 6543,
    DATABASE postgres,
    USER 'your-user',
    PASSWORD 'your-password'
);

ATTACH 'ducklake:postgres:dbname=postgres' AS ducklake_catalog;
USE ducklake_catalog;

And exploring the datasets that has been written :

Copy code
-- Explore your data
SHOW TABLES;
SELECT * FROM ducklake_catalog.snapshots();

-- Verify Spark writes
SELECT COUNT(*) FROM spark_sales_data;
SELECT * FROM spark_sales_data LIMIT 5;

-- Time travel queries
SELECT COUNT(*) FROM spark_sales_data AT (VERSION => 1);

You understand now that it's really easy to switch between Spark and DuckDB for interactive exploration.

Looking Forward: The Future of Spark + DuckLake

Working with this integration has been a glimpse into the future of data architectures. While the marriage between Apache Spark and DuckLake is still in its honeymoon phase, it's already showing promise for teams that want the best of both worlds.

What excites me most about this combination is how it preserves the simplicity that makes DuckDB so appealing while unlocking the ecosystem that Spark provides.

The JDBC integration has some rough edges, the partitioning optimization requires manual tuning, and the documentation is still catching up. But these are the growing pains of any powerful new integration.

You can start simple with your existing Spark setup and DuckLake, and leverage after some pure DuckDB workload on top of the same storage.

Give it a try, break things, and let me know what you discover.
