Redshift Files: the Hunt for Big Data

Assumptions

In order to make sense of these queries, I needed to make a handful of assumptions.

The Redshift instances in the dataset are representative of the larger user base.

As is mentioned in the github repository: “Redset is not intended to be representative of Redshift as a whole. Instead, Redset provides biased sample data to support the development of new benchmarks for these specific workloads.“ While this reduces the strength of some of the conclusions in this post, this dataset remains one of the best sources for understanding data sizes and shapes in real world workloads.

What’s more, it is unlikely that this data is biased towards the small size; the paper makes the case that the long tail is important to look at, and it would be surprising if they de-emphasized the long tail. What’s more, some of the conclusions in the paper would be weakened if the data is not representative of the broader fleet. For example, they have discussions about the shapes of data, growth of tables, and the number of rows that are typically found, and these wouldn’t hold up if the data wasn’t nearly representative.

Table Size estimation is hard.
If all you have are scan sizes, then it is hard to know the full size of the table. Most analysis doesn’t require this, but a couple of the queries do rely on being able to figure out which tables are “big” and which are not. To figure out what tables are “big”, I pick the largest scan of the table by itself. This may under-count the table size in some cases. However, it may also over-count the table size, since there seem to be cases where the same table gets read multiple times.

Note that the technique we are using here, looking at the maximum query size ever run on a table, will often significantly under-count the size of a table. However, in a world with separation of storage and compute, if you don’t read parts of a table, it might as well not exist for the purposes of query execution. That is, if you have a partitioned table that sits on disk with 10 years of logs and you only ever scan the last 7 days, then the 9.9 years of logs that you don’t scan don’t impact things at all. The query engine you’re using doesn’t have to handle 10 years of logs.

While it is true that at some point you might decide you need to look at the whole dataset (after all, that’s likely why you keep it around), do you want to design your data architecture and query engine around something you might want to do a couple of times a year, or what you do thousands of times a day? Virtually any system will be able to crunch through the giant data set eventually, it might just take a long time.

The Boundary between Small Data and Big Data is 10 TB
The definition of “Big Data” has always been a bit vague, but the one I find most instructive is that Big Data starts when you need to scale out to multiple machines in order to process the data in a reasonable amount of time.

At MotherDuck, we have built a scale up hosted version of DuckDB, and we have a lot of happy customers running databases that are several terabytes when compressed. So 10 TB as a boundary point for “Big Data” seems reasonable from an “existence proof” perspective.

If you wanted to draw a finer line, you might want to differentiate between scan size and storage size. A scan size of 1TB might be considered big data, but you wouldn’t consider your stored data to actually be “Big Data” until you had more than 10TB (or more). However, this still wouldn’t meaningfully change the results. More than 99% of users still never scan more than a Terabyte at once, and 98% of queries against instances that have big data scan less than 1TB. For the purposes of simplicity I drew the line at 1TB across the board.

Preparing Data

To do this analysis, I used MotherDuck, but you can use any query engine you’d like. You can run all of these queries yourself in MotherDuck by following along.

If you’d like to use the MotherDuck UI, you can navigate to https://app.motherduck.com and sign up. It is easy, and doesn’t require a credit card. You can also run from the DuckDB CLI. To do this on a Mac, you can run brew install duckdb.

You can get the redset dataset by attaching the share that I created. Run the following command in either the MotherDuck UI, the DuckDB CLI, or your favorite DuckDB environment:

Copy code
ATTACH 'md:_share/redset/dff07b51-2c00-48d5-9580-49cec3af39e4'

If you run the above command in MotherDuck or DuckDB, it will attach a MotherDuck share called redset that has the full redset dataset already loaded.

Alternatively, you can load the data from S3 yourself with the following commands in MotherDuck or DuckDB:

Copy code
--- Alternate setup, loading data directly ---
CREATE TABLE serverless as
SELECT * FROM 's3://redshift-downloads/redset/serverless/full.parquet';
CREATE TABLE provisioned as
SELECT * FROM 's3://redshift-downloads/redset/provisioned/full.parquet';

In order to make queries run faster and simplify some of the queries (so they are easier to share), I created a handful of temp tables that compute various statistics about the data. To create the scratch database, I ran:

Copy code
CREATE OR REPLACE DATABASE scratch;

I also created a couple of useful helper functions. The first is pow_floor, which we use to create power-of-10 buckets by truncating a value to the nearest power of 10. So 59.3 would be 10, 5930 would be 1000. This is useful to enable us to see how things change with regard to order of magnitude changes in the data.The gb_range macro translates the output of pow_floor into something that describes the data range.

Copy code
CREATE OR REPLACE MACRO pow_floor(x) AS pow(10,log(10,x+0.01)::bigint)::bigint;

CREATE OR REPLACE MACRO gb_to_label(size_gb) AS
  CASE WHEN size_gb < 1000        THEN CONCAT(size_gb, 'GB')
       WHEN size_gb < 1000 * 1000 THEN CONCAT((size_gb / 1000)::bigint, 'TB')
       ELSE CONCAT((size_gb / 1000 / 1000)::bigint, 'PB') END;

CREATE OR REPLACE MACRO gb_range(size_gb) AS
  CASE WHEN size_gb = 0 then '< 1 GB'
  CASE WHEN size_gb > 0 then
      CONCAT('[', gb_to_label(size_gb), ' - ', gb_to_label(size_gb * 10), ')')
  ELSE 'N/A' end

Now, let’s look at the data. We want to create a consistent view that we’ll use across all of our queries that filters out stuff we don’t care about, and makes sure we’re looking at the right things.

Copy code
CREATE OR REPLACE VIEW scratch.all_queries as
SELECT * FROM (SELECT * FROM provisioned UNION ALL
  SELECT * REPLACE (instance_id + (SELECT max(instance_id) from provisioned) + 1 as instance_id) from serverless
)
WHERE query_type not in ('unload', 'other', 'vacuum') and was_aborted = 0 and mbytes_scanned is not null

The Redshift data comes in two different tables, provisioned and serverless. If we want to query all of the data, we need to query across both of them. Luckily, they have the same schema, but unluckily, they have overlapping instance IDs. So if we want to query across both of them, we need to remap the instance IDs so they don’t overlap.

We also are going to skip over query types unload, other and vacuum because they aren’t useful for seeing what kinds of analytics people are doing.

For our analysis, we want to understand how big the tables are, but unfortunately, that information isn’t directly available. We just know how much data was scanned per query, but some queries scan many tables, and some scan only parts of a table.

To get an estimate, I use the largest single-table query done for each table and use that as the table size.

This is not an exact method of computing query size; some tables that are created from a summary might be much smaller, or the user may never query the full table size. However, if the user never reads the full table size, then the full table size likely doesn’t matter; what matters is the proportion that is used.

Here is the basic query for figuring out table size:

Copy code
CREATE OR REPLACE TABLE scratch.table_sizes as
SELECT try_cast(read_table_ids as bigint) as table_id,
  instance_id, database_id,
  max(if(num_scans > 0, mbytes_scanned / num_scans, mbytes_scanned)) / 1000 as table_gb
FROM scratch.all_queries
WHERE num_permanent_tables_accessed < 2 and num_external_tables_accessed = 0
  and num_system_tables_accessed = 0
  and table_id is not null
GROUP BY ALL

This query is pretty straightforward. I look only at cases where a single table was queried (since it would be hard to attribute size to a different table) and skip anything that reads system tables or external tables, since that will affect the scan size.

Note that we play a little bit of a trick to get the table ID; since we are only looking for queries that query one table, a comma separated list of tables. The read_table_ids field will be just a string representation of the single table. So we cast it to a bigint. If it fails the cast, it must not have been a single table query. We also divide by the number of scans done, since sometimes the same table gets scanned multiple times.

Next, we want to compute the size of tables involved in a query. We already have the amount of data scanned, but we also want to learn what the full size of the relevant tables are. This query saves it in a temp table:

Copy code
CREATE OR REPLACE TABLE scratch.queries_and_sizes as
WITH queries as (
SELECT
  query_id, database_id, instance_id, user_id,
  regexp_split_to_array(read_table_ids, ',') as table_id_array,
  mbytes_scanned / 1024 as scanned_gb
FROM scratch.all_queries
WHERE num_external_tables_accessed = 0 and query_type = 'select'
  and len(table_id_array) > 0
),
queries_and_scan_sizes as (
SELECT query_id, instance_id, database_id, user_id, scanned_gb,
  try_cast(tid.table_id_array as bigint) as table_id,
FROM queries, UNNEST(table_id_array) tid
WHERE table_id is not null
)
SELECT query_id, instance_id, database_id, user_id,
  sum(table_gb) total_table_gb, any_value(scanned_gb) as scanned_gb,
  count(*) as table_count
FROM queries_and_scan_sizes q
JOIN scratch.table_sizes using(table_id, database_id, instance_id)
GROUP BY ALL

This query is a little bit complicated because the list of tables scanned is in a comma-separated varchar field. So we first split the list to an array, and then flatten by the table ID. We match the table ID up against our saved table size table, and compute the sum of all table sizes in the query. Also, we are only looking at SELECT queries for this one, since we generally care most about analytics queries, not queries that are transforming data.

Analysis Queries

Now we’ve got the base tables set up, and we can move onto the queries to figure out how the data is being used.

Copy code
SELECT pow_floor(mbytes_scanned/1000) as query_gb,
  gb_range(query_gb) as query_size,
  COUNT(1) / SUM(COUNT(1)) OVER () as pct,
  SUM(execution_duration_ms) /  SUM(SUM(execution_duration_ms)) OVER () as elapsed_pct,
FROM scratch.all_queries
GROUP BY ALL
ORDER BY 1 DESC

Copy code
WITH db_sizes as (
  SELECT instance_id, database_id, max(mbytes_scanned/1000) as scanned_gb
  FROM scratch.all_queries
  WHERE  num_external_tables_accessed = 0 and num_permanent_tables_accessed > 0
  GROUP BY ALL
)
SELECT
  pow_floor(scanned_gb) as db_gb,
  gb_range(db_gb) as db_size,
  COUNT(1) / SUM(COUNT(1)) OVER() as pct,
  COUNT(1) as db_count
FROM db_sizes
GROUP BY ALL
ORDER BY db_gb DESC

Copy code
WITH user_sessions as (
  SELECT user_id, instance_id,
    DATE_TRUNC('HOUR', arrival_timestamp) as session_ts,
    max(mbytes_scanned) / 1000 as max_scanned_gb
  FROM scratch.all_queries
  GROUP BY ALL
)
SELECT pow_floor(max_scanned_gb) as scanned_gb,
  gb_range(scanned_gb) as scan_size,
  COUNT(DISTINCT (user_id, instance_id))/
    SUM(COUNT(DISTINCT (user_id, instance_id))) OVER() as pct_user,
  COUNT(*)/SUM(COUNT(*)) OVER( ) as pct_session,
from user_sessions
where scanned_gb is not null
GROUP BY ALL
ORDER BY 1 DESC

Copy code
SELECT
  pow_floor(table_gb) as total_table_gb,
  gb_range(total_table_gb) as table_size,
  COUNT(1) / SUM(COUNT(1)) OVER () as pct,
  COUNT(1) as table_count
FROM scratch.table_sizes
GROUP BY ALL
ORDER BY 1 DESC

Copy code
WITH instance_sizes as (
  SELECT instance_id, database_id,
  max(mbytes_scanned/1000.0
      * IF(num_scans > num_permanent_tables_accessed, num_permanent_tables_accessed/num_scans, 1)) as max_scanned_gb
  FROM scratch.all_queries
  WHERE num_external_tables_accessed = 0  and num_permanent_tables_accessed > 0
  GROUP BY ALL
),
big_data_instances as (
  SELECT instance_id
  FROM instance_sizes
  WHERE max_scanned_gb > 10 * 1000
),
big_data_users as (
  SELECT COUNT(DISTINCT (user_id, instance_id)) as user_count
  FROM scratch.queries_and_sizes
  JOIN big_data_instances using (instance_id)
)
SELECT
  pow_floor(total_table_gb) as total_table_gb_out,
  gb_range(total_table_gb_out) as total_table_size,
  count(*)/sum(count(*)) over () as query_pct,
  COUNT(DISTINCT (user_id,instance_id))/(SELECT user_count from big_data_users) as user_pct,
FROM scratch.queries_and_sizes
JOIN big_data_instances using (instance_id)
GROUP BY ALL
ORDER BY 1 DESC

Copy code
SELECT
  pow_floor(total_table_gb) as total_table_gb_out,
  gb_range(total_table_gb_out) as total_table_size,
  approx_quantile(scanned_gb / total_table_gb, 0.5) as scan_pct_50,
  approx_quantile(scanned_gb / total_table_gb, 0.9) as scan_pct_90,
  approx_quantile(scanned_gb, 0.5) as scan_50,
  approx_quantile(scanned_gb, 0.9) as scan_90,
FROM scratch.queries_and_sizes
GROUP BY ALL
ORDER BY 1 DESC

Copy code
SELECT
  pow_floor(scanned_gb) as scanned_gb_out,
  gb_range(scanned_gb_out) as scan_size,
  COUNT(1)/SUM(COUNT(1)) OVER() as query_pct,
  COUNT(1) as query_count
FROM scratch.queries_and_sizes
WHERE total_table_gb > 10 * 1000
GROUP BY ALL
ORDER BY 1 DESC
